Home » Projects » Nucor Steel Memphis bar mill automation upgrade
  • Home
  • Nucor Steel Memphis bar mill automation upgrade
2023 - Memphis, TN - USA

Nucor Steel Memphis bar mill automation upgrade

Located in TN, Nucor Steel Memphis is upgrading the bar mill automation. Russula is providing the automation equipment, engineering and on-site services of installation supervision, commissioning and training.

Scope of Supply

By upgrading existing hardware with technologically advanced systems, retrofitting increases automation equipment functionality and reliability. This extends the system lifecycle and decreases the need for maintenance in the future.

The existing Rockwell control system will be reused. A new rolling mill control application designed by Russula will be installed including: recipes, mill setup, interlocking, automatic cobble detection, impact speed drop compensation, minimum tension control, phamtom billet, crop and dividing shear control. After the upgrade the mill will be controlled by two CPUs. New HMI applications will be supplied for mill operations and maintenance. New operations and control desks, fabricated in Russula's workshop, will also be supplied.

Nucor Memphis

Nucor Memphis team at Russula headquarters for the Factory Acceptance Test

Factory Acceptance Test

In the second quarter of 2023, The Nucor Memphis team visited the Russula headquarters in A Coruña, Spain for the Factory Acceptance Test, which verified the peformance of the systems: HMI, PLC I/O, network hardware and operator desks. The team also visited the Russula workshop, in Bergondo, A Coruña to check the new operation and control desks that were subsequently shipped to Memphis.

About Nucor Steel Memphis
Nucor Steel Memphis produces special bar quality (SBQ) steel using an electric arc furnace (EAF). The mill, which Nucor began operating in 2009, melts recycled scrap metal and turns it into new carbon and alloy steel engineered bar products for the automotive, agriculture, construction, mining, heavy truck, oil and gas, and rail applications.The steel produced contains 90 percent recycled material.
